Printing Method Digital 5 LED Full-color Electrophotographic Printing Method
Media Format Roll
Media Type Plain Paper, Film, Plain Paper Label, Glossy Paper Label, Film Label, Synthetic paper Label
Media Width 25.4 - 130.0mm
Media Thickness 0.076 - 0.25mm
Label Length 12.7 - 1,320.8mm
Label Width 25.4 - 126.0mm
Media Detection Gap Black Mark (printed on back of liner)None
Roll Outer Diameter Max. Ф203.2mm (Ф8")
Core Inner Diameter Ф76.2mm (Ф3")
Roll Wind Direction Face-out, Face-in
Print Width Max. 125.76mm
Minimum Print Margin Top:2.12mmBottom:2.12mmRight:2.12mmLeft:2.12mm
Cuttable Media Length Min. 101.6mm
Print Resolution 1200 x 1200 dpi600 x 600 dpi
Print Speed Max. 152.4mm/s (6ips)
Interface1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed)
Protocol TCP/IP
Printer Language PCL 5c emulation, PCL 6 (XL) emulation, Adobe PostScript 3
Supported OS (Click here for latest OS)Windows 10, Windows 10 x64, Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Server 2016, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64
Processor ARM CPU 1.2 GHz
Memory (Std./Max.)2048 MB / 2048 MB
Hard Disk Drive 250 GB
Font Adobe PostScript 136 fonts, PCL emulation 81 scalable fonts, 4 bitmap fonts
Media Sensors Position adjustable Transmission Gap SensorPosition adjustable Reflective Black Mark (printed on back of liner) Sensor
Auto Cutter Rotary blade Full cut
Dimensions (WxDxH)1,040 x 477 x 441 mm
Weight(includes supplies)Approx. 62.0 kg
Weight(not includes supplies)Approx. 50.0 kg
Operating Environment Operating: 10 - 30 °C, 20 - 70 %RHNo condensation
Power Source Single phase 230 VAC ±10%, 50/60 Hz ±2%
Power Consumption Operating: Max. 1,200W / Ave. 740WIdle: 27WPower Save: < 25.0W
Safety& Environment Regulation GS Mark, GS Mark, CE Mark
Unit Life 5 Years
In the Box DVD-ROM, Power cable
