Dimensions (W x L x H): 720mm x 1700mm x 1350mm
Laminating Speed: 12m/min max
Paper Size (W x L):
• Max: 380mm x 500mm (option: 1200mm)
• Min: 180mm x 210mm
Sleeking: Gloss, Matte, Hologram, Metallic
Substrate Thickness: 120 ~ 350/m
Front Roller Diameter:
• Top: High glossy chrome ø100
• Bottom: Silicon ø80
Rear Roller Diameter: Silicon ø55
Power Requirements: AC 220~240V, 50/60Hz, 15A
Power Consumption: 2.8 kw
Warm-up Time: 5 min.
Heating System: Infrared Heater
Laminating Temperature: Max. 150ºc
Temperature & Speed Control: Capacitive Touch Screen
Roller Pressure: Pneumatic Cylinder
Film Core Size: 77mm (3") / Dual - 58mm, 50mm
Air Compressor: 1 HP, 89L / min
Temperature Sensing Method: Thermo-couple inserted in the roller shell
Net Weight: 187kg
