Dimensions (W x L x H) 720mm x 1700mm x 1350mm
Laminating Speed 12m/min max
Paper Size (W x L)
• Max: 380mm x 500mm (option: 1200mm)
• Min: 180mm x 210mm
Sleeking Gloss, Matte, Hologram, Metallic
Substrate Thickness 120 ~ 350/m
Front Roller Diameter
• Top: High glossy chrome ø100
• Bottom: Silicon ø80
Rear Roller Diameter Silicon ø55
Power Requirements AC 220~240V, 50/60Hz, 15A
Power Consumption 2.8 kw
Warm-up Time 5 min.
Heating System Infrared Heater
Laminating Temperature Max. 150ºc
Temperature & Speed Control Capacitive Touch Screen
Roller Pressure Pneumatic Cylinder
Film Core Size 77mm (3") / Dual - 58mm, 50mm
Air Compressor 1 HP, 89L / min
Temperature Sensing Method Thermo-couple inserted in the roller shell
Net Weight 187kg
